CyberPower SNEV001 - Environmental Sensor
The CyberPower SNEV001 is a compact environmental monitoring sensor designed to rapidly integrate with CyberPower Remote Management Cards (RMCARD series) or network-enabled PDUs. It provides real-time temperature and humidity readings, along with dry-contact inputs, enhancing visibility into critical rack or room conditions.
Key Features
Real-time monitoring of temperature (–10 °C to 70 °C / 14 °F to 158 °F ±0.5 °C) and humidity (10–90% RH ±2%)
Two RJ45 ports allowing daisy‑chaining of up to 8 units for multi‑location sensing
Four dry-contact inputs support monitoring of devices like door switches, security sensors, or alarms
Status LED indicator for quick operational status checks
Mounting flexibility, including hook-and-loop or fixed screw mounting options, suitable for rack interiors or wall installations
Technical Specifications
| Specification | Detail |
|---|---|
| Temperature Range | –10 °C to 70 °C (14 °F–158 °F), ±0.5 °C |
| Humidity Range | 10–90% RH, ±2% non‑condensing humidity |
| Dry-Contact Inputs | 4 independent input channels |
| Daisy-Chain Support | Up to 8 units via 2× RJ45 ports |
| Power Input | 7–28 V DC |
| Dimensions (W×D×H) | 53 × 29 × 67 mm (2.63″ × 1.14″ × 2.08″) |
| Weight | ~48 g (1.69 oz) |
| Certifications | CE, FCC Class B, EAC, RoHS |
Use Cases & Benefits
Proactive environment alerts: Automatically trigger notifications via connected RMCARD devices when thresholds are exceeded (e.g. overheat, high humidity).
Multi-zone sensing: Daisy chain multiple sensors for temperature and humidity mapping across server racks, closets, or different physical zones.
Dry-contact monitoring: Track auxiliary systems like door alarms or switches for holistic environmental oversight.
Seamless integration: Works with CyberPower’s RMCARD205, RMCARD305, and compatible PDUs for unified management via web interface or software.
Compatibility
Engineered to pair with CyberPower RMCARD series, such as the RMCARD205 and RMCARD305, and compatible with selected network-enabled PDUs and ATS units.
